📌 Project Overview

Project Title: W5500 Ethernet Module Initialization with MIotKit

Video Link: Lesson 5.2 - MIotKit Initialization: Configuring W5500

Creator: 懒惰的猪妖 (Lazy Pig Demon, developer of MIotKit)

Platform: MIotKit (STM32-based development board) + WIZnet W5500 Ethernet module

Operating System: hl_miniOS (custom RTOS)

Development Environment: Keil MDK5

🧩 Components Used

MIotKit Development Board: An STM32-based IoT development board

WIZnet W5500: A hardware TCP/IP offload Ethernet controller

RJ45 Ethernet Port: For physical Ethernet connectivity through W5500

⚙️ Project Description

This project demonstrates how to connect the W5500 Ethernet module to the MIotKit board and perform its initial configuration for Ethernet communication. The video walks through the necessary steps to configure W5500 registers, assign network parameters, and initiate SPI communication.

Key Steps Covered:

Connecting W5500 and Powering Up
The W5500 is connected to the MIotKit board via SPI. Proper power supply and stable connection are ensured.

Setting Up SPI Interface
The STM32 microcontroller’s SPI peripheral is configured to communicate with the W5500.

Configuring Network Parameters
IP address, subnet mask, gateway, and other network parameters are written to the W5500’s registers using SPI.

Testing Data Communication
After setup, the system performs a basic test to confirm data transmission over Ethernet.

🧠 Learning Highlights

How to initialize and configure the W5500 Ethernet module

Implementing SPI communication between STM32 and W5500

Understanding how to set up wired networking using static IP configurations

Exploring network stack fundamentals in a lightweight RTOS (hl_miniOS) environment

🧰 Related Resources

W5500 Datasheet & Documentation: WIZnet Official Docs

MIotKit Board Information: Available via Taobao - Hailin IoT Electronics Store

hl_miniOS Overview: Developer Blog
